Compact overall layout and novel structure: Incorporates independent innovation and international advanced technology for excellent performance.
Advanced microcomputer control: PLC module allows for automatic, semi-automatic, and manual joint control. Features real-time dynamic simulation and fault self-diagnosis.
High Precision: Employs electronic measurement with an advanced double-stroke method, providing automatic compensation and high measuring accuracy.
Environmental Friendly: Fully sealed design with low noise and high-standard dust emission controls.
Reliability: Core components are assembled with imported parts to ensure long-term equipment stability.
| Content / Type | LB-1000 Specifications |
|---|---|
| Rated productivity (t/h) | 60-80 |
| Mixing capacity (kg/batch) | 1000 |
| Total installed capacity (kw) | 260 |
| Fuel consumption rate (kg/t) | ≤6.5 |
| Type of fuel | Diesel fuel, heavy oil, natural gas |
| Finished material temperature (ºC) | 140-160 |
| Ore materials accuracy (%) | ≤±0.3 |
| Asphalt materials accuracy (%) | ≤±0.1 |
| Powder metering accuracy (%) | ≤±0.2 |
| Ambient noise [dB(A)] | ≤80 |
| Dust emission [mg/Nm3] | ≤100 |
